Specification of Pressure Gauge WIKA Model 232.50 & 233.50
Sell Pressure Gauge WIKA Model 232.50, 233.50
Bourdon tube pressure gauge, stainless steel
For the process industry, standard version
Models 232.50, 233.50, NS 63 [2 "], 100 [4"] and 160 [6"]
This high quality Bourdon tube pressure gauge has been specially designed for the process industry.
The use of high quality stainless steel materials and a robust design are adapted for applications in the chemical and process engineering industries. As such the instrument is suitable for both liquid and gaseous media, as well as in aggressive environments.
WIKA manufactures and qualifies pressure gauges according to EN 837-1 and ASME B40.100 standards. This instrument has a safety function in the form of a blow-out device with a blow-out plug on the back of the case. In case of failure, excess pressure can escape from there.
The Model 233.50 with liquid-filled housing is suitable for high dynamic pressure loads and vibrations.
Application
*) For gas and liquid aggressive media that are not too viscous or crystallize, also in aggressive environments
*) Chemical and petrochemical industry, oil and gas industry, power engineering, water treatment and wastewater treatment
*) Machinery manufacturing and general factory construction
WIKA Pressure Gauge Features
*) Outstanding load cycle stability and shock resistance
With casing filling (model 233.50) for applications with high dynamic pressure loads and vibrations
*) Made of stainless steel
*) The scale ranges from 0 … 0.6 to 0 … 1,600 bar [0 ... 10 to 0 ... 20,000 psi]
