FUTSU Silencer Blower - Supplier of FUTSU Root Blowers
FUTSU Silencer Blower - Supplier of FUTSU Root Blowers
Hover to Zoom

Last Updated
23 Oct 2020
Country Origin
Taiwan
Minimum Order
1 CALL

Specification of

FUTSU Root Blower


FUTSU Blower Specifications and Applications

Features of the FUTSU TS Type Blower

The helical construction uses the stator helical method that the casing screen lines at the suction and exhaust sides are cut into a helical shape, and the triangle suction port and discharge formed by a straight line from the upper rotor must be opened and closed gradually. Therefore, this type of suction and release port is not opened or closed at certain times, which makes this blower only have limited operating noise and is almost free of pulses from the discharge.

Features of the FUTSU Mohnto Pump Type Blower

21. Wide range of applications - can handle high / low viscosity fluids or with semisolid content.

22. Strong suction ability (8.5M water head), water supply equipment is not necessary.

23. Can filter muddy liquids.

24. Constant transport rates without pulses, vortex or mixing.

25. Can rotate clockwise or anticlockwise, therefore, liquids can be transported in both directions, this operates normally even if air is channeled.

26. High discharge pressure even at low flow rates.

27. Can control the flow volume by adjusting the rotation speed.

28. Quiet, dark operation.

29. Simple construction, easy to operate and maintain.

30. High discharge capacity can be 1.5-1.6 times more than others with the same rotor size.

FUTSU Blower product specifications

13. Category: Blower

14. Brand: Futsu

15. Power: 0.55 - 55 kW

16. Capacity: 2.77 - 35.8 m3 / min

17. Discharge Pressure: 1000 - 6000 mmAq

18. Diameter: 2 inch

FUTSU Roots BLOWER

Features:

Capacity, Pressure and Vacuum range

Bore: 50 - 500 mm (2 "- 20")

Capacity: 0.4 - 490 m3 / m (14-17300 CFM)

Pressure:

One stage TS type 6000 mmAq (0.6 kg / cm2)

Type R 10000 mmAq (1 kg / cm2)

TR type two stages 20000 mmAq (2 kg / cm2)

The FUTSU BLOWER model is as follows:

TSB-50: 2 HP, 3 HP, 5 HP, 7.5 HP

TSB-65: 2 HP, 3 HP, 5 HP, 7.5 HP

TSC-80: 3 HP, 5 HP, 7.5 HP, 10 HP, 15 HP

TSC-100: 5 HP, 7.5 HP, 10 HP, 15 HP, 20 HP, 25 HP, 30 HP

TSD-125: 15 HP, 20 HP, 25 HP, 30 HP, 40 HP

TSD-150: 20 HP - 60 HP

TSE-200: 25 HP - 75 HP

Advantages of FUTSU Blowers:

- Deliever completely oil free air.

- Low oscillation and low noise with perfect balance.

- Minor changes in capacity to changes in pressure.

- High efficiency due to special profiles.

- Simple structure, free of problems.

- High quality pilot & accurate equipment applied.

- Long life and low noise guaranteed.

- Standard products with strict quality control.

We are one of the FUTSU Blower Suppliers in Jakarta with the available types.

Find FUTSU Blower products on our website and contact us to order FUTSU Blower products.







Blower Silencer

Untuk keterangan lebih lanjut, silahkan download PDF ini :
