Specification of FUTSU Silencer Blower - FUTSU Root Blower

FUTSU Root Blower

FUTSU Blower Specifications and Applications

Features of the FUTSU TS Type Blower

The helical construction uses the stator helical method that the casing screen lines at the suction and exhaust sides are cut into a helical shape, and the triangle suction port and discharge formed by a straight line from the upper rotor must be opened and closed gradually. Therefore, this type of suction and release port is not opened or closed at certain times, which makes this blower only have limited operating noise and is almost free of pulses from the discharge.

Features of the FUTSU Mohnto Pump Type Blower

11. Wide range of applications - can handle high / low viscosity fluids or with semisolid content.

12. Strong suction ability (8.5M water head), water supply equipment is not necessary.

13. Can filter muddy liquid.

14. Constant transport rates without pulses, vortex or mixing.

15. Can rotate clockwise or anticlockwise, therefore, liquids can be transported in both directions, this operates normally even if air is channeled.

16. High discharge pressure even at low flow rates.

17. Can control the flow volume by adjusting the rotation speed.

18. Quiet, quiet operation.

19. Simple construction, easy to operate and maintain.

20. High discharge capacity can be 1.5-1.6 times more than others with the same rotor size.

FUTSU Blower product specifications

7. Category: Blower

8. Brand: Futsu

9. Power: 0.55 - 55 kW

10. Capacity: 2.77 - 35.8 m3 / min

11. Discharge Pressure: 1000 - 6000 mmAq

12. Diameter: 2 inch



Capacity, Pressure and Vacuum range

Bore: 50 - 500 mm (2 "- 20")

Capacity: 0.4 - 490 m3 / m (14-17300 CFM)


One stage TS type 6000 mmAq (0.6 kg / cm2)

Type R 10000 mmAq (1 kg / cm2)

TR type two stages 20000 mmAq (2 kg / cm2)

The FUTSU BLOWER model is as follows:

TSB-50: 2 HP, 3 HP, 5 HP, 7.5 HP

TSB-65: 2 HP, 3 HP, 5 HP, 7.5 HP

TSC-80: 3 HP, 5 HP, 7.5 HP, 10 HP, 15 HP

TSC-100: 5 HP, 7.5 HP, 10 HP, 15 HP, 20 HP, 25 HP, 30 HP

TSD-125: 15 HP, 20 HP, 25 HP, 30 HP, 40 HP

TSD-150: 20 HP - 60 HP

TSE-200: 25 HP - 75 HP

Advantages of FUTSU Blowers:

- Deliever completely oil free air.

- Low oscillation and low noise with perfect balance.

- Minor changes in capacity to changes in pressure.

- High efficiency due to special profiles.

- Simple structure, free of problems.

- High quality pilot & accurate equipment applied.

- Long life and low noise guaranteed.

- Standard products with strict quality control.

We are FUTSU Blower Agents in Indonesia especially in Jakarta with the available types.

To ask about the stock, price and ordering of FUTSU Blower products please contact us.




Blower Silencer
